| Price
BAVG |
RAS10N3KV2-E1/N3AV2 | RAS13N3KV2-E1/N3AV2 | RAS16N3KV2-E1/N3AV2 | RAS18N3KV2-E1/N3AV2 | RAS22N3KV2-E1/N3AV2 |
|---|---|---|---|---|---|
| All prices are inclided VAT and excluded installation costs. BGN |
1 400,00 | 1 600,00 | 1 900,00 | 2 020,00 | 2 330,00 |
All prices are inclided VAT and excluded installation costs.
| Efficiency data
BAVG |
RAS10N3KV2-E1/N3AV2 | RAS13N3KV2-E1/N3AV2 | RAS16N3KV2-E1/N3AV2 | RAS18N3KV2/N3AV2 | RAS22N3KV2/N3AV2 | ||
|---|---|---|---|---|---|---|---|
| Cooling capacity Min./Nom./Max. kW |
2,5 (1,1-3,0) | 3,5 (1,1-4,05) | 4,5 (0,8-5,0) | 5,0 (1,1-6,0) | 6,0 (1,2-6,7) | ||
| Heating capacity Min./Nom./Max. kW |
3,2 (0,9-4,8) | 4,2 (1,0-5,3) | 5,5 (0,9-6,9) | 5,8 (0,8-6,3) | 7,0 (1,0-7,5) | ||
| Seasonal efficiency (сaccording to EN14825) |
Cooling | Energy efficiency class | A++ | A++ | A++ | A++ | A++ |
| SEER | 6,7 | 6,5 | 6,1 | 7,0 | 6,5 | ||
| Seasonal electricity consumption kWh |
137 | 189 | 258 | 250 | 323 | ||
| Heating (Average climate) | Energy efficiency class | A+ | A+ | A | A+ | A+ | |
| SCOP/A | 4,3 | 4,0 | 3,9 | 4,1 | 4,0 | ||
| Seasonal electricity consumption kWh |
944 | 1 119 | 1 362 | 1 400 | 1 645 | ||
|
Technical data - Indoor unit BAVG |
RASB10N3KV2-E1 | RASB13N3KV2-E1 | RASB16N3KV2-E1 | RAS18N3KV2-E1 | RASB22N3KV2-E1 | ||
|---|---|---|---|---|---|---|---|
| Dimensions | Unit (HeightxWidthxDepth) |
mm |
275x790x217 | 275x790x217 | 275x790x217 | 320x1050x229 | 320x1050x229 |
| Air filter | Type |
|
IAQ filter | IAQ filter | IAQ filter | IAQ filter | IAQ filter |
| Sound pressure level | Cooling / Heating |
dBA |
38/26 39/28 |
39/26 -40/28 |
45/30 45/31 |
44/32 44/32 |
47/35 47/35 |
|
Technical data - Outdoor unit BAVG |
RAS10N3AV2-E1 | RAS13N3AV2-E1 | RAS16N3AV2-E | RAS18N3AV2-E | RAS22N3AV2-E | |||
|---|---|---|---|---|---|---|---|---|
| Dimensions | Unit (HeightxWidthxDepth) |
mm |
550x780x290 | 550x780x290 | 550x780x290 | 550x780x290 | 550x780x290 | |
| Sound pressure level | Cooling / Heating |
dBA |
46/47 | 48/50 | 49/50 | 49/50 | 53/52 | |
| Operation range | Cooling (Ambient Min.~Max.) |
°CDB |
-10~46 | -10~46 | -10~46 | -10~46 | -10~46 | |
| Heating (Ambient Min.~Max.) |
°CWB |
-15~24 | -15~24 | -15~24 | -15~24 | -15~24 | ||
| Refrigerant | Type | R-410A | R-410A | R-410A | R-410A | R-410A | ||
