| Price
BAVG |
RAS10BKV/BAV | RAS13BKV/BAV | RAS16BKV/BAV |
|---|---|---|---|
| All prices are inclided VAT and excluded installation costs. BGN |
1 120,00 | 1 245,00 | 1 590,00 |
All prices are inclided VAT and excluded installation costs.
| Efficiency data
BAVG |
RAS10BKV/BAV | RAS13BKV/BAV | RAS16BKV/BAV | ||
|---|---|---|---|---|---|
| Cooling capacity Min./Nom./Max. kW |
2,5 (0,67-3,1) | 3,1 (0,75-3,5) | 4,4 (1,1-4,8) | ||
| Heating capacity Min./Nom./Max. kW |
3,2 (0,7-3,9) | 3,6 (0,7-4,5) | 5,2 (0,8-6,1) | ||
| Seasonal efficiency (сaccording to EN14825) |
Cooling | Energy efficiency class | A+ | A+ | A+ |
| SEER | 5,6 | 5,7 | 5,9 | ||
| Seasonal electricity consumption kWh |
156 | 190 | 261 | ||
| Heating (Average climate) | Energy efficiency class | A+ | A+ | A+ | |
| SCOP/A | 4,0 | 4,0 | 4,2 | ||
| Seasonal electricity consumption kWh |
840 | 980 | 1 333 | ||
|
Technical data - Indoor unit BAVG |
RAS10BKV-E | RAS13BKV-E | RAS16BKV-E | ||
|---|---|---|---|---|---|
| Dimensions | Unit (HeightxWidthxDepth) |
mm |
293x798x230 | 293x798x230 | 293x798x230 |
| Air filter | Type |
|
Hepa&Cold Catalyst filter | Hepa&Cold Catalyst filter | Hepa&Cold Catalyst filter |
| Sound pressure level | Cooling / Heating |
dBA |
40/23 41/23 |
41/24 45/24 |
44/25 43/26 |
|
Technical data - Outdoor unit BAVG |
RAS10BAV-E | RAS13BAV-E | RAS16BAV-E | |||
|---|---|---|---|---|---|---|
| Dimensions | Unit (HeightxWidthxDepth) |
mm |
530x660x240 | 530x660x240 | 550x780x290 | |
| Sound pressure level | Cooling / Heating |
dBA |
48/50 | 48/50 | 49/50 | |
| Operation range | Cooling (Ambient Min.~Max.) |
°CDB |
-15~46 | -15~46 | -15~46 | |
| Heating (Ambient Min.~Max.) |
°CWB |
-15~46 | -15~46 | -15~46 | ||
| Refrigerant | Type | R410A | R410A | R410A | ||
