| Price
FTXJ + RXJ |
20MW + 20M | 20MS + 20M | 25MW + 25M | 25MS + 25M | 35MW + 35M | 35MS + 35M | 50MW + 50N | 50MS + 50N |
|---|---|---|---|---|---|---|---|---|
| Unit price (indoor unit + outdoor unit + remote control)
BGN |
2.728,- | 2.785,- | 2.877,- | 2.940,- | 3.363,- | 3.425,- | 4.403,- | 4.482,- |
All prices are inclided VAT and excluded installation costs.
| Efficiency data FTXJ + RXJ |
20MW/S + 20M | 25MW/S + 25M | 35MW/S + 35M | 50MW/S + 50N | ||
|---|---|---|---|---|---|---|
| Cooling capacity Min./Nom./Max. kW |
1,3/2,3/2,8 | 1,3/2,4/3,0 | 1,4/3,5/3,8 | 1,7/4,8/5,3 | ||
| Heating capacity Min./Nom./Max. kW |
1,3/2,5/4,3 | 1,3/3,4/4,5 | 1,4/4,0/5,0 | 1,7/5,8/6,5 | ||
| Seasonal efficiency (сaccording to EN14825) |
Cooling | Energy efficiency class | A+++ | A+++ | A++ | A++ |
| SEER | 8,73 | 8,64 | 7,19 | 7,02 | ||
| Annual energy consumption kWh |
92 | 97 | 170 | 239 | ||
| Heating (Average climate) | Energy efficiency class | A++ | A++ | A++ | A+ | |
| SCOP/A | 4,61 | 4,60 | 4,60 | 4,28 | ||
| Annual energy consumption kWh |
638 | 822 | 913 | 1.505 | ||
| Technical data - Indoor unit FTXJ |
20MW/S | 25MW/S | 35MW/S | 50MW/S | ||
|---|---|---|---|---|---|---|
| Dimensions | Unit (HeightxWidthxDepth) |
mm |
303x998x212 | 303x998x212 | 303x998x212 | 303x998x212 |
| Air filter | Type |
|
Removable / washable / mildew proof | Removable / washable / mildew proof | Removable / washable / mildew proof | Removable / washable / mildew proof |
| Sound pressure level | Cooling / Heating |
dBA |
38/25/19 40/28/19 |
38/25/19 41/28/19 |
45/26/20 45/29/20 |
46/35/32 47/35/32 |
| Technical data - Outdoor unit RXJ |
20M | 25M | 35M | 50N | |||
|---|---|---|---|---|---|---|---|
| Dimensions | Unit (HeightxWidthxDepth) |
mm |
550x765x285 | 550x765x285 | 550x765x285 | 735x825x300 | |
| Sound pressure level | Cooling / Heating |
dBA |
46/43 47/44 |
46/43 47/44 |
48/45 48/45 |
48/45 48/45 |
|
| Operation range | Cooling (Ambient Min.~Max.) |
°CDB |
-10~46 | -10~46 | -10~46 | -10~46 | |
| Heating (Ambient Min.~Max.) |
°CWB |
-15~18 | -15~18 | -15~18 | -15~18 | ||
| Refrigerant | *Type/Charge kg-TCO₂Eq/GWP | R-32/0,72/ 0,5/675 |
R-32/0,72/ 0,5/675 |
R-32/0,72/ 0,5/675 |
R-32/1,30/ 0,9/675 |
||
