Series DIAMOND 2017

Advantages:

  • Inverter air conditioner, white;
  • 3D AUTO - 3 Independent Swing Valve Motors;
  • Ultra High SEER / SCOP;
  • Heating to -20оС, Cooling to -15оС;
  • Increased power output, reduced consumption
  • Moisture sensor;
  • Mode "Silent", "Powerful", "Night 10оС", "Auto Restart", "Hot Start", "AUTO Comfort";
  • 4 speed internal fan
  • Weekly timer, 24-hour timer;
  • Illuminated buttons on the remote control;
  • Self-cleaning feature
  • 4-way valve adjustment from the remote control.
  • Made in Thailand.



Price SRK20ZSX-S/    SRC-20ZSX-S SRK25ZSX-S/    SRC-25ZSX-S SRK35ZSX-S/    SRC-35ZSX-S SRK50ZSX-S/    SRC-50ZSX-S SRK60ZSX-S/    SRC-60ZSX-S
All prices are inclided VAT and excluded installation costs.

BGN

- - - - -

(-) Направи запитване за цена. All prices are inclided VAT and excluded installation costs.

Technical data:

Efficiency data SRK20ZSX-S/    SRC-20ZSX-S SRK25ZSX-S/    SRC-25ZSX-S SRK35ZSX-S/    SRC-35ZSX-S SRK50ZSX-S/    SRC-50ZSX-S SRK60ZSX-S/    SRC-60ZSX-S
Cooling capacity Min./Nom./Max.

kW

2,0 (0,9-3,2) 2,5 (0,9-3,7) 3,5 (1,0-4,3) 5,0 (1,0-5,8) 6,1 (1,0-6,8)
Heating capacity Min./Nom./Max.

kW

2,7 (0,8-5,3) 3,2 (0,9-5,8) 4,3 (0,9-6,6) 6,0 (0,6-8,1) 6,8 (0,6-8,7)
Seasonal efficiency
(сaccording to EN14825)
Cooling Energy efficiency class A+++ A+++ A+++ A++ A++
SEER 9,5 9,6 9,2 8,2 7,6
Annual energy consumption

kWh

- - - - -
Heating (Average climate) Energy efficiency class A+++ A+++ A+++ A++ A++
SCOP/A 5,2 5,2 5,1 4,7  4,7
Annual energy consumption

kWh

- - - - -

Technical data - Indoor unit

SRK20ZSX-S SRK25ZSX-S SRK35ZSX-S SRK50ZSX-S SRK60ZSX-S
Dimensions Unit (HeightxWidthxDepth)

mm

305/920/220 305/920/220 305/920/220 305/920/220 305/920/220
Air filter Type



Self-cleaning / Allergen-deactivating / Photocatalytic washing deodorizing Self-cleaning / Allergen-deactivating / Photocatalytic washing deodorizing Self-cleaning / Allergen-deactivating / Photocatalytic washing deodorizing Self-cleaning / Allergen-deactivating / Photocatalytic washing deodorizing Self-cleaning / Allergen-deactivating / Photocatalytic washing deodorizing
Noise level Cooling / Heating

dBA

19/24/31/38
19/25/32/38
19/25/33/39
19/27/34/40
19/26/35/43
19/28/35/41
22/31/39/44
23/33/41/46
22/33/41/46
23/34/42/46

Technical data - Outdoor unit

SRC-20ZSX-S SRC-25ZSX-S SRC-35ZSX-S SRC-50ZSX-S SRC-60ZSX-S
Dimensions Unit (HeightxWidthxDepth)

mm

640x800(+71)x290 640x800(+71)x290 640x800(+71)x290 640x800(+71)x290 640x800(+71)x290
Noise level Cooling / Heating

dBA

43/44 44/45 48/47 50/49 52/52
Operation range Cooling
(Ambient Min.~Max.)

°CDB

-15~46 -15~46 -15~46 -15~46 -15~46
Heating
(Ambient Min.~Max.)

°CWB

-20~24 -20~24 -20~24 -20~24 -20~24
Refrigerant *Type/Charge kg-TCO₂Eq/GWP R410А/1,45/
3,028/2088
R410А/1,45/
3,028/2088
R410А/1,45/
3,028/2088
R410А/1,5/
3,132/2088
R410А/1,5/
3,132/2088

(-) No manufacturer data is available.

Funcitons:

  1. Power saving features
    Adaptive Predictive Management; Sensor movement; Eco operation; Auto Off;
  2. Air Flow Functions
    Jet technology; 3D auto; Automatic air distribution valves; Storing the position of the flaps; Rotating the air distribution valves in the vertical direction; Rotating the air distribution valves in the horizontal direction;
  3. Cleaning operations and filters
    Allergen-deactivation system; Self-cleaning function; Allergen-deactivating filter; Photocatalytic washing deodorizing filter; Detachable panel;
  4. Functions for comfort and convenience
    Drying mode; Hi Power mode; Quiet mode; Night care; Weekly timer; 24-hour programmable on / off timer; Sleep Mode; On / Off Timer; Comfort start; Saved mode (New!); Lock for children; Adjusting the brightness of the indicator lights (New!); Mounting positioning;
  5. Other features
    Microcomputer defrost; Self-diagnosis function; Automatic restart function;
