Series BASE CLASS R32

Advantages:

  • Inverter, color - white, EEV, Wi-Fi-preparation
  • Very high SEER, high SCOP
  • High power
  • "Heating": up to -15оС
  • "Cooling": up to + 5оС
  • "Quiet" mode 20 dBa - only 9 and 12
  • "Powerful" mode
  • 5 speed internal fan
  • Made in Malaysia



Price CS/CU-KE25TKE CS/CU-KE35TKE CS/CU-KE50TKE
All prices are inclided VAT and excluded installation costs.

BGN

1 100,00 1 200,00 1 900,00

All prices are inclided VAT and excluded installation costs.

Technical data:

Efficiency data CS/CU-KE25TKE CS/CU-KE35TKE CS/CU-KE50TKE
Cooling capacity Min./Nom./Max.

kW

2,5 (0,85-3,0) 3,4 (0,85-3,9) 5,0 (0,98-5,4)
Heating capacity Min./Nom./Max.

kW

3,15 (0,8-3,6) 3,84 (0,8-4,4) 5,4 (0,98-7,5)
Seasonal efficiency
(сaccording to EN14825)
Cooling Energy efficiency class A++ A++ A++
SEER 6,2 6,1 6,2
Annual energy consumption

kWh

- - -
Heating (Average climate) Energy efficiency class A+ A+ A+
SCOP/A 3,8 3,8 3,9
Annual energy consumption

kWh

- - -
Technical data - Indoor unit CS/CU-KE25TKE CS/CU-KE35TKE CS/CU-KE50TKE
Dimensions Unit (HeightxWidthxDepth)

mm

290/850/199 290/850/199 290/870/214
Air filter



PM2 PM2 PM2
Sound pressure level  Cooling / Heating

dBA

20/37 20/38 34/44
Technical data - Outdoor unit CS/CU-KE25TKE CS/CU-KE35TKE CS/CU-KE50TKE
Dimensions Unit (HeightxWidthxDepth)

mm

- - -
Sound pressure level  Cooling / Heating

dBA

- - -
Operation range Cooling
(Ambient Min.~Max.)

°CDB

5~- 5~- 5~-
Heating
(Ambient Min.~Max.)

°CWB

-15~- -15~- -15~-
Refrigerant *Type R-410A R-410A R-410A



Funcitons:

  1. "Hot Start"
  2. "AUTO Restart"
  3. "AUTO Comfort"
  4. 24h timer
  5. Wire remote control - option
